Round Fluted

Features



alt

  • Load bearing
  • Powder coat paint finish
  • Available in seven colors
  • Cast aluminum capitals and bases
  • Virtually maintenance free
  • Class 1 Flame Spread classification
  • Architectural fluting
  • 6 SKUs packaged with capital & base in same box with column
  • Common sizes ship within 48 hours
  • Wraps around existing post (modification may be necessary)
  • Ideal for commercial & residential applications

 Specifications

ROUND FLUTED COLUMNS
Size Weight
(lbs.)
Dimensions *Centered
Load Limit
A B C
6"  x   8' 19 6" 7-9/16" 1-3/4" 20,000 lbs.
6"  x   9' 21 6" 7-9/16" 1-3/4" 20,000 lbs.
6"  x 10' 23 6" 7-9/16" 1-3/4" 20,000 lbs.
8"  x   8' 24 7-5/8" 9-7/16" 2-3/16" 21,000 lbs.
8"  x   9' 27 7-5/8" 9-7/16" 2-3/16" 21,000 lbs.
8"  x 10' 30 7-5/8" 9-7/16" 2-3/16" 21,000 lbs.
8"  x 12' 32 7-5/8" 9-7/16" 2-3/16" 21,000 lbs.
8"  x 16' 40 7-5/8" 9-7/16" 2-3/16" 21,000 lbs.
8"  x 18' 50 7-5/8" 9-7/16" 2-3/16" 21,000 lbs.
8"  x 20' 62 7-5/8" 9-7/16" 2-3/16" 21,000 lbs.
10" x   8' 33 9-3/8" 11-1/4" 2-3/8" 26,000 lbs.
10" x   9' 36 9-3/8" 11-1/4" 2-3/8" 26,000 lbs.
10" x 10' 38 9-3/8" 11-1/4" 2-3/8" 26,000 lbs.
10" x 12' 47 9-3/8" 11-1/4" 2-3/8" 26,000 lbs.
10" x 16' 63 9-3/8" 11-1/4" 2-3/8" 26,000 lbs.
10" x 18' 67 9-3/8" 11-1/4" 2-3/8" 26,000 lbs.
10" x 20' 75 9-3/8" 11-1/4" 2-3/8" 26,000 lbs.
12" x   8' 52 11-1/2" 15-1/8" 2-3/4" 30,000 lbs.
12" x   9' 58 11-1/2" 15-1/8"

2-3/4"

30,000 lbs.

12" x 10' 65 11-1/2" 15-1/8" 2-3/4" 30,000 lbs.
12" x 12' 75 11-1/2" 15-1/8" 2-3/4" 30,000 lbs.
12" x 16' 99 11-1/2" 15-1/8" 2-3/4" 30,000 lbs.
12" x 18' 102 11-1/2" 15-1/8" 2-3/4" 30,000 lbs.
12" x 20' 115 11-1/2" 15-1/8" 2-3/4" 30,000 lbs.
12" x 24' 130 11-1/2" 15-1/8" 2-3/4" 30,000 lbs.
15" x 12' 115 14-1/2" 18-3/4" 4-3/4" 33,000 lbs.
15" x 16' 123 14-1/2" 18-3/4" 4-3/4" 33,000 lbs.
15" x 18' 140 14-1/2" 18-3/4" 4-3/4" 33,000 lbs.
15" x 20' 155 14-1/2" 18-3/4" 4-3/4" 33,000 lbs.
15" x 24' 170 14-1/2" 18-3/4" 4-3/4" 33,000 lbs.
18" x 16' 182 17-3/4" 22-1/2" 5" 38,000 lbs.
18" x 18' 198 17-3/4" 22-1/2" 5" 38,000 lbs.
18" x 20' 215 17-3/4" 22-1/2" 5" 38,000 lbs.
18" x 24' 247 17-3/4" 22-1/2" 5" 38,000 lbs.
24" x 18' 295 23-1/2" 28-7/8" 7-3/4" 43,000 lbs.
24" x 20' 320 23-1/2" 28-7/8" 7-3/4" 43,000 lbs.
24" x 24' 370 23-1/2" 28-7/8" 7-3/4" 43,000 lbs.

*Load-bearing capacity is dependent on distributing the load evenly over bearing surfaces of the shaft. All installation information is of general nature; columns should be installed and secured (fastened) according to standard construction practices and in compliance with applicable local, state and federal building regulations. Note: 2nd story balconies should not be attached directly to the side of any column.

Colors
available:


  Gloss White Wicker Clay White Tex Bronze Tex Black Tex Brown Tex
